SeoJin Instech Co., Ltd.

SEOJIN INSTECH PRODUCTS

Separated Type Electromagnetic Flowmeter

The measurement principle of the electron flow meter (AceMag) applies Faraday's law of electromagnetic induction and Fleming's law.
The Faraday's Law of Induction, which state that an induced electromotive force is generated in a conductor when it moves through a magnetic field, form the basis for the electromagnetic flowmeter measurements. This measurement principle is applied to a conductive fluid that flows in a pipe in which a magnetic field is generated perpendicular to the flow direction.
It can be used to accurately measure the flow rate of fluids with electrical conductivity greater than 5㎲/cm.

Separated Type Electromagnetic Flowmeter

DISPLACEMENT TYPE LEVEL TRANSMITTER

- For the safe and efficient operation of various high temperature and high pressure steam drums, boilers and reactors used in Firepower Plants, Glass & Cement Plants, Petrochemical Plants and Steel & Paper manufacturing Plants, close monitoring and controlling of the interface level between water and vapor is very important. As these steam drums are working under extremely high temperature and pressure conditions, the instruments related to measuring and controlling the level must be defect-free. Otherwise, minor defects may bring serious damages to the other equipments or financial losses.

- However the industry had relied on the instruments like Sight Glass or Float Type Level switches and had experienced many troubles so the demand for the alternative instruments had increased. To respond to this market demand, Seojin committed to the development of Displacement Type Level Transmitter based on its experiences and know-how, and finally has succeeded in launching this model to the market. Our Displacement Type Level Transmitter can assure the reliable operation even under the harsh circumstance like 200㎏f/㎠ and 450℃.

- This Displacement Type Level Transmitter is designed for measuring not only the level of on liquid but also the interface level between two different liquids. Its operation is based on the buoyancy principles of Archimedes and it supports remote monitoring by the configuration with PC (With SIEMENS PDM Software) or Universal Hand Held Terminal (HART Field Communicator). This instrument also supports the conventional way of operation and control so the users can operate and control it using keypads at the field.

Vertical Float Type Level Switch

The electric contact switch operates as per the principle of magnetism, and the electric contact switch is normally relay-off " position because of tension spring.
There is magnetic steel on the edge of Float's Rod, and this magnetic steel sticks to magnet installed inside the housing when the level goes up.
At this time, electric contact switch turns on because the switch designed to "relay- on" when the magnet sticks to magnetic steel of the Float s Rod. When the level goes down , on the contrary, the Float goes down and accordingly the magnetic steel on the Float s edge goes down.
Therefore, the magnetic steel detaches from the magnet and the switch is returning to "relay-off" position due to tension spring.

ABOUT SEOJIN INSTECH

Seojin Instech is a specialized company in the area of field instrumentation like Level Sensors and Flowmeters, and has been playing important roles in the wide ranging industries from Building Automation & Factory Automation to Hydro, Thermal and Nuclear Power Plant for the past 36 years under the management philosophies of Customer Satisfaction, Professionalism and Responsibility Management.
We’re proud of ourselves that we have been constantly developing and manufacturing the high quality products on the basis of our technologies and experiences which enabled us to provide our customers with the high quality services.
Based on these experiences and technical expertise, we are focusing on securing the core technologies in the measurement instrument industry, striving to become a leading comprehensive instrument manufacturing company in the future.
We promise to always do our best based on change, innovation, and trust.
